ABB 134177-001—01 Servo drive module

ABB 134177-001—01 Servo drive module

This module is the core driving component of the robot’s electrical system. It is responsible for receiving control signals from the main computer and converting them into precise current and voltage to drive the servo motor of a joint of the robot. It ensures the accuracy, speed and stability of the robot’s movement.

Key Features and Detailed Specifications

1. Product Type:

   • It is a single-axis or dual-axis drive module. Whether it drives one or two motors depends on its position within the IRC5 drive module assembly. In a typical IRC5 architecture, drive modules are installed in groups to collectively control all 6 (or more) axes of the robot.

2. Technical Specifications:

   • Input Power: Accepts DC power from the DC bus (e.g., +/- 550VDC or +/- 650VDC, depending on the controller model).

   • Output: Provides three-phase Pulse Width Modulation (PWM) output, connected directly to the servo motor.

   • Control Technology: Utilizes advanced Digital Signal Processors (DSP) for closed-loop control, enabling high-precision torque, speed, and position control.

   • Communication Interface: Communicates in real-time with the Main Computer (main board) via an internal high-speed bus.

3. Physical Appearance:

   • A typical electronic board, integrated with large capacitors, power transistors (IGBTs), heat sinks, connectors, status indicator lights (LEDs), and various interfaces.

   • Usually housed in a black metal casing that acts as a heat sink.

4. Role within the System:

   • It is a key component of the Drive Module unit in an ABB IRC5 controller.

   • It works in conjunction with the Main Computer module, Axis Computer module, and other drive modules.

   • Specifically, it executes motion commands from the Axis Computer and provides real-time feedback on the motor’s actual status (e.g., position, current).

Common Applications

This drive module is specifically designed to drive servo motors on ABB industrial robot manipulators, widely used in:

• Automotive manufacturing (welding, painting, handling)

• Metal fabrication

• Plastics industry

• Electronics assembly

• Food and beverage industries, among others.
