Bently 350093135785-01 Relay Module

Detailed Product Description

1. Product Function and Application
The 3500/93 relay module is an “actuator” unit in the Bently Nevada 3500 rack system. Its primary function is to receive alarm or dangerous shutdown signals from monitor modules (such as the 3500/42 and 3500/25) and then control external devices through its built-in physical relay contacts.

Simply put, it acts like an automatic switch. When a machine fault occurs, it immediately activates, disconnecting the circuit or activating protective devices to prevent equipment damage or escalating the incident.

Main functions include:

Alarm indication: Activates the alarm light or audible and visual alarm on the control panel to alert the operator.

Interlock control: Triggers the shutdown solenoid valve, closes the air intake valve, and other functions to achieve automatic shutdown.

Safety interlock: As part of the safety loop, it ensures that the equipment cannot be started or must be shut down in an unsafe state.

Signal relay: Transmits system status signals to the DCS (distributed control system) or PLC (programmable logic controller).

2. Key Features
Four Independent Relay Channels: A 3500/93 module typically contains four independent relays (C, D, E, and F channels), each of which can be configured to respond to different alarm conditions.

Flexible Configuration: The 3500 series configuration software allows you to flexibly configure each relay channel’s driving source (from which monitor channel’s alarm or danger signal) and action logic (e.g., alarm activation, danger activation, normal state activation, etc.).

Relay Status Indicator: LED indicators on the module’s front panel clearly display the current status of each relay channel (energized/de-energized).

Form C Contacts (Changeover Contacts): Each relay channel provides a set of normally open (NO), normally closed (NC), and common (COM) dry contacts, providing strong compatibility and connection to a variety of external devices.

High Reliability: Designed for harsh industrial environments, it offers high interference immunity and stability, making it a core component of critical equipment protection systems.

3. Typical Application Scenarios
The 3500/93 relay module is widely used in industries requiring critical equipment protection, such as:

Oil and gas: compressors, pumps, and gas turbines.

Power industry: steam turbines, gas turbines, generators, and large water pumps.

Chemical industry: various high-speed rotating equipment.

Metallurgy, papermaking, and other heavy industries.
