The DeltaV Controller Redundancy Kit is not a single device, but rather a bundle containing all the core hardware required to build a complete, high-availability controller unit.Its core design goal is to provide redundant, high-reliability control functionality for Emerson’s DeltaV distributed control system (DCS).

Detailed Product Description

1. Product Name and Role

• Product Name: DeltaV Controller Redundancy Kit

• Product Role: Acts as the “brain” of the DeltaV system. It is responsible for executing control logic, processing input/output signals, communicating with operator stations and other network nodes, and ensuring bumpless switchover in case of a single component failure to maintain continuous operation.

2. Core Components

This “kit” typically includes the following key components:

• 2 x MD Controllers: These are the core of the kit. The MD Controller is the workhorse multi-purpose controller for the Emerson DeltaV system.

  • Model Example: EMERSON DeltaV MD Cntrlr 4xAI 2xAO 8xDI 4xDO (e.g., KJ3001X1-BA1 or other variants).

  • Function: Each controller contains a powerful processor and memory to run user-configured control strategies (e.g., PID control, sequential control, logic operations).

• 1 x Controller Base/Chassis: This is a physical chassis designed to house two MD controllers simultaneously.

  • Function: It provides power, communication bus connections for both controllers, and manages the redundancy switchover logic between them. The two controllers (one primary, one standby) are tightly synchronized through this base.

• 2 x Power Supplies: Typically configured as redundant power supplies to power the entire controller unit (including both controllers and the base), further enhancing system reliability.

• Necessary Connectors and Accessories: Includes terminal blocks, cables, etc., for connecting to the control and I/O networks.

3. Key Features & Functions

• Redundancy: This is the most critical feature. The two controllers operate in a “primary-standby” mode. The primary controller executes all control tasks online, while the standby controller synchronizes all data and state in real-time. If the primary controller fails (hardware, power, communication loss), the standby controller takes over control within milliseconds without disruption, ensuring continuous process operation.

• High Reliability: Designed for 24/7 continuous operation in demanding industrial environments (e.g., chemical, oil & gas, pharmaceuticals, power generation).

• High Performance: MD Controllers possess powerful processing capabilities for rapidly executing complex control algorithms and scanning large numbers of I/O points.

• Seamless Integration: Integrates seamlessly into the DeltaV system network, communicating with operator stations, engineering stations, and application stations via the DeltaV Control Network.

• Hot Swappable: Supports hot swapping of controllers and power modules. This allows for the replacement and maintenance of faulty modules without shutting down the process or impacting production.

• Deterministic Control: Provides predictable, periodic control execution, ensuring consistent and reliable control loop response times.

4. Position in the DeltaV System Architecture

In a typical DeltaV system structure, the KJ3004X1-BA1 redundant controller resides at the control layer:

1. Field Layer: Sensors, actuators connected via fieldbus to…

2. I/O Layer: DeltaV I/O card racks (CHARMs or traditional I/O cards).

3. Control Layer: The KJ3004X1-BA1 Redundant Controller communicates with the I/O card racks via the I/O link to acquire process data and output control signals.

4. Operation & Monitoring Layer: Operator and engineering stations communicate with the controllers over the Control Network for monitoring and configuration.

5. Typical Applications

Widely used in process industries requiring high availability and safety:

• Chemical and Petrochemical Plants

• Oil Refineries

• Pharmaceutical and Biotechnology

• Oil and Gas Production & Pipelines

• Power Generation

• Food and Beverage

• Water and Wastewater Treatment
