Siemens 6ES7153-1AA03-0XB0

This is a PROFIBUS DP slave interface module for the ET 200SP system. It serves as a key bridge between the flexible ET 200SP I/O modules and the traditional PROFIBUS network. With its high reliability, powerful diagnostic capabilities, and easy configuration, it has long been widely used in industrial automation.

Core Product Overview

• Product Name: IM 153-1 Interface Module

• System: SIMATIC ET 200SP

• Primary Function: To act as a PROFIBUS DP slave, connecting the ET 200SP distributed I/O station to a PROFIBUS-DP fieldbus network.

Detailed Product Description

1. Product Role and Position

The IM 153-1 interface module is the “brain” or “gateway” of an ET 200SP distributed I/O station. It is mounted at the far left end of the station (the start of the base unit assembly) and is responsible for:

• Network Communication: Exchanging data at high speed with the superior PROFIBUS master (e.g., an S7-300/400 PLC, S7-1500 PLC with DP interface) via its PROFIBUS-DP interface.

• Station Management: Managing all I/O modules in the station, packaging their input/output data, and cyclically transmitting it via the PROFIBUS network to and from the master.

• Power Distribution: Supplying the internal electronic power required for the subsequent I/O modules.

2. Key Features and Parameters

• Interface Type: PROFIBUS DP

• Protocol: Complies with PROFIBUS-DP V0/V1 standard.

• Baud Rate: Auto-sensing, up to 12 Mbps.

• PROFIBUS Address Setting: Set via the DIP switch on the module, range 1-126.

• Maximum I/O Capacity:

  • Input Data: Up to 244 bytes

  • Output Data: Up to 244 bytes

  • (Total for the entire ET 200SP station)

• Maximum Number of Modules: One IM 153-1 can connect up to 32 I/O modules.

• Diagnostics: Supports powerful diagnostic functions (e.g., bus fault, station fault, module fault). Diagnostics are reported via LED indicators and PROFIBUS telegrams to the master for quick troubleshooting.

• Firmware Update: Supports online firmware updates without removing the module.

• Required Base Unit: Must be installed on a BU…P type base unit (e.g., BU15-P or BU20-P).

• Operating Mode: Pure DP Slave.

3. Product Appearance and Indicators

The module features several LED indicators for displaying operational status and diagnostics:

• ON: Power indicator

• BF: Bus Fault indicator

• SF: System Fault indicator (e.g., I/O module fault)

• RUN/STOP: Run/Stop status

Typical Application Scenarios

The IM 153-1 is widely used in automation systems requiring distributed, modular I/O control, especially in:

• Factories that already use PROFIBUS-DP as their backbone network.

• Applications where large amounts of field signals (digital/analog) need to be collected from remote equipment and sent to a central controller.

• Systems where multiple distributed slaves are connected on a single PROFIBUS bus to save wiring costs and space.

• Examples: Automotive manufacturing, packaging machinery, conveyor systems, process control.
