It is a high-performance, high-reliability differential protection relay produced by ABB.

1. Core Product Overview

• Product Name: RED521 Differential Protection Relay

• Product Model: 1MRK002003-BA

• Primary Function: This is a digital differential protection relay designed for medium-voltage power networks. Its core purpose is to protect critical electrical assets such as transformers, generators, and motors.

• Product Family: It belongs to ABB’s renowned Relion® product family and is a member of the 620 series. This series is known for its advanced protection, control, monitoring, and communication capabilities.

2. Key Features & Functions

The core of the RED521 is to provide fast, sensitive, and selective differential protection to prevent damage from internal faults.

• Main Protection Functions:

  • Differential Protection: Detects internal faults by comparing the vector sum (differential current) of the currents entering and leaving the protected equipment. This is the primary and fastest protection function.

  • Percentage Differential Protection with 2nd Harmonic Restraint: Effectively distinguishes between fault currents and transformer inrush currents (generated during energization), preventing false trips.

  • High-Impedance Differential Protection: Offers an optional high-impedance differential scheme, particularly suitable for protecting busbars.

• Backup & Additional Protection Functions:

  • Overcurrent Protection: Provides definite-time and inverse-time overcurrent protection as a backup.

  • Earth-Fault Protection: Sensitive earth-fault and directional earth-fault protection.

  • Overload Protection: Monitors the thermal capacity of the equipment and provides an alarm or trip signal.

  • Non-Electrical Protection: Can interface with devices like Buchholz relays and temperature gauges via binary inputs to initiate tripping.

• Advanced Characteristics:

  • Powerful Fault Recording: Capable of recording current and voltage waveforms and data before, during, and after a fault for detailed analysis.

  • Measurement & Monitoring: Real-time monitoring of electrical parameters like current, voltage, power, energy, and frequency.

  • Event Logging: Detailed recording of all operations, alarms, and fault events with precise timestamps.

  • Communication Capabilities: Supports multiple industry-standard protocols such as IEC 61850 (Station and Process Level), Modbus, IEC 60870-5-103/104, enabling seamless integration into digital substations.

  • Human-Machine Interface (HMI): Features a clear LCD display and navigation keys on the front panel for local viewing and settings.

3. Typical Applications

The RED521 is widely used in power systems requiring high-reliability protection, especially for:

• Power Transformer Protection (two-winding or three-winding)

• Large Generator and Motor-Generator Protection

• Large High-Voltage Motor Protection

• Busbar Protection

• Critical Distribution Systems in industrial sectors (e.g., petrochemical, steel, data centers)
