EMERSON DeltaV KJ3004X1-EA1 Safety controller module

EMERSON DeltaV KJ3004X1-EA1

The DeltaV Controller is a complete, highly integrated “Safety Controller Module”. It is a key component of the Emerson DeltaV system, especially its safety system series.

EMERSON DeltaV KJ300X1-BB1 Product Description

1. Core Product Positioning & Series

• Product Series: DeltaV SIS (Safety Instrumented System) series.

• Core Function: It is a CHARMs (CHARacterization Module) Safety Controller in the Electronic Marshalling form factor. CHARMs are the core processing units of the DeltaV SIS system.

2. Key Features & Functionality

• Safety Integrity Level (SIL):

  • Compliant with IEC 61508 and certified for SIL 3 operation.

  • Compliant with IEC 61511 for the process industry.

  • This designates it for high-reliability safety functions, such as Emergency Shutdown (ESD), Burner Management Systems (BMS), and overpressure protection, to prevent hazardous events or mitigate their consequences.

• Integrated Architecture:

  • Controller and I/O in One: The KJ3004X1-BB1 module itself integrates the controller and specific safety I/O channels. It is a fully functional unit, not an empty card slot.

  • Electronic Marshalling: Utilizes DeltaV’s pioneering Electronic Marshalling technology. This technology decouples field wiring from the controller logic via a separate “CHARMs Carrier” and “Terminal Base,” eliminating the need for traditional marshalling cabinets. This simplifies design, installation, commissioning, and maintenance, allowing for signal reassignment without system shutdown.

• Processing Power:

  • The module is a powerful logic solver capable of executing complex safety logic.

  • It runs the DeltaV SIS proprietary operating system and logic configuration, ensuring deterministic and highly reliable performance.

• Diagnostics & Reliability:

  • Features extensive built-in self-diagnostics that continuously monitor the health of the module, including the processor, memory, communications, and power.

  • Designed with redundancy and fault-tolerance in mind. It can be paired with an identical module to form a redundant pair, ensuring high availability and safe operation even in the event of a single component failure.

• Communication:

  • Seamlessly integrates with the DeltaV network via its backplane, enabling secure and reliable communication with the DeltaV Process Control System (DCS).

  • Supports SIS-to-DCS communication, allowing operators to view the safety system’s status (without the ability to modify safety logic) from a standard operator station, enabling operational and safety integration.

3. Physical Design & Appearance

• It is a modular card designed to be installed in a DeltaV system cabinet.

• It requires insertion into a dedicated CARRIER module, which provides power, communication backplane connectivity, and the interface to the field wiring terminal bases.

• The unit is typically a robust electronic module with a metal heatsink casing. The front features status LEDs (e.g., Run, Fault, Active) for quick diagnostics.

4. Typical Applications

The KJ3004X1-BB1 is used in critical process control applications requiring high safety integrity, such as:

• Oil & Gas: Emergency Shutdown (ESD) systems for offshore platforms, pipeline Emergency Shutdown (ESD) systems.

• Chemical Industry: Reactor over-temperature and over-pressure protection, interlocked shutdown systems.

• Petrochemical Industry: Compressor anti-surge systems, Fire & Gas (F&G) detection systems.

• Power Generation: Boiler Master Fuel Trip (MFT) systems.

• Pharmaceutical Industry: Interlock protection for critical batch processes.
