Hirschmann MS4128-L2P

Hirschmann MS4128-L2P

The Hirschmann 1000 is a high-performance, rugged, fully managed Layer 2 industrial Ethernet switch from the German brand Hirschmann (a Belkin company). It belongs to Hirschmann’s classic MS (Modular Switch) series and is designed for stable operation in harsh and critical industrial environments.

Core Product Features

1. Industrial-Grade Design and Reliability

   • Rugged Housing: Features a metal housing that provides a high degree of Electromagnetic Compatibility (EMC) protection and mechanical strength.

   • Wide Operating Temperature: Supports an extended operating temperature range from -40°C to +75°C (-40°F to +167°F), making it suitable for outdoor or factory floor applications in extreme climates.

   • Fanless Design: Utilizes passive cooling with no moving parts, enhancing device reliability, service life, and preventing downtime caused by fan failure.

   • Redundant Power Inputs: Provides 2 independent 24 V DC power inputs, supporting power redundancy to ensure continuous system operation even if one power line fails.

2. Network Performance and Port Configuration

   • Port Quantity & Type: 24 x 10/100Base-T(X) copper Ethernet ports and 2 x Gigabit SFP (mini GBIC) slots.

   • Uplink Flexibility: The 2 Gigabit SFP slots can be used for fiber or copper uplinks, providing higher bandwidth and longer transmission distances for easy connection to the network backbone.

   • Plug-and-Play: In the default configuration, all ports have auto-negotiation and Auto-MDI/MDI-X enabled, allowing for quick deployment.

3. Advanced Network Management Features (Fully Managed)

   • Comprehensive Layer 2 Features: Supports VLAN (IEEE 802.1Q), Quality of Service (QoS/CoS), Port Mirroring, Link Aggregation (LACP/Static), and Rapid Spanning Tree Protocol (RSTP), enabling granular control and management of network traffic.

   • Security Features: Offers port security (e.g., MAC address filtering), 802.1X-based network access control, and multi-level user management (read/write/administrator privileges) to ensure network security.

   • Network Redundancy Protocols: In addition to standard STP/RSTP, it supports Hirschmann’s proprietary HIPER-Ring and MRP (Media Redundancy Protocol, compliant with IEC 62439-2), achieving ring network recovery times of less than 0.2 seconds to build highly available network topologies.

4. Suited for Industrial Automation & Mission-Critical Applications

   • IT/OT Convergence: Supports network management protocols like SNMP (v1, v2c, v3), LLDP, and RMON for easy integration into unified network management systems.

   • Clock Synchronization: Supports IEEE 1588 PTP (Precision Time Protocol), meeting the requirements of applications with high demands for time synchronization, such as motion control and power systems.

   • Certifications & Standards: Certified with various industrial standards such as UL/cUL, ATEX, DNV GL, IEC 61850-3, and IEEE 1613 (for power), proving its suitability for demanding industrial sectors.

Technical Specification Summary

Typical Application Scenarios

• Factory Automation: Connecting PLCs, HMIs, drives, sensors, and cameras.

• Process Control: Oil & gas, chemical, and pharmaceutical industries.

• Energy Sector: Substations, power plants, distribution automation.

• Transportation: Railway signaling systems, tunnel monitoring, highway management systems.

• Urban Infrastructure: Building automation, water and waste treatment facilities.
