This high-quality, high-performance single-pole 16A miniature circuit breaker is from ABB’s acclaimed S200 series. It is primarily used for overload and short-circuit protection of terminal distribution circuits and is a very common and core safety component in building electrical installations. Its C-type design and 16A rated current make it ideal for protecting conventional sockets and lighting circuits.

ABB 3BUS208796-501 Product Description

1. Core Product Information

• Product Series: System Pro M compact S200

• Product Type: Miniature Circuit Breaker (MCB)

• Number of Poles: 1P (Single Pole)

• Rated Current: 16 A

• Breaking Capacity: 6 kA (According to IEC/EN 60898 standard)

• Tripping Characteristic: C-Curve (Instantaneous tripping current between 5 In and 10 In. Suitable for general lighting, distribution, and socket-outlet circuits, capable of withstanding standard inrush currents from devices like refrigerators and small motors.)

2. Key Features & Functions

• Overload Protection: The bi-metallic strip heats and bends when the current exceeds the rated value (16A) for a prolonged period, triggering a trip to prevent cable overheating and fire.

• Short-Circuit Protection: The magnetic trip mechanism instantaneously disconnects the circuit in the event of a high short-circuit current (within the C-curve range).

• Mechanical Life: Over 20,000 operations, ensuring high mechanical durability.

• Electrical Life: Over 10,000 operations at rated current.

• Termination: Features cage-clamp spring technology for quick, reliable, and vibration-resistant connection of both rigid and flexible conductors.

• Standards Compliance: Conforms to international standards such as IEC/EN 60898 and IEC/EN 60947-2.

3. Physical Design & Installation

• Modular Width: 18mm (1 Standard Module)

• Mounting: Standard DIN rail mounting (35mm symmetrical rail per EN 60715).

• Appearance: Typically a white housing with an orange trip indicator and an operating handle.

4. Typical Applications

This 16A, C-curve, single-pole MCB is widely used in residential, commercial, and light-industrial low-voltage electrical installations for:

• Lighting circuits in homes and offices

• General-purpose socket-outlet circuits

• Distribution and protection for small household appliances (e.g., TVs, computers, vacuum cleaners)

5. Full Model Number Breakdown

• 3BUS208796-501 is ABB’s internal order number or material code.

• In the market, this product is more commonly identified as: S201M-C16

  • S2: System Pro M compact S200 Series

  • 01: 1 Pole

  • M: Modular size

  • C: C-type tripping curve

  • 16: 16 Ampere rated current
