Description

Emerson DeltaV 73-610-115 DCDC

The CMOS is a DC/DC converter module, often referred to as a “power conditioning module” or “isolator module.” Its primary function is to provide a safe, reliable, and regulated DC power supply to the DeltaV system’s field devices while providing electrical isolation to protect the system core from field interference and faults.







Emerson DeltaV 73-610-115 DCDC Module Product Description

1. Core Overview

The Emerson DeltaV 73-610-115 is a DC/DC Converter Module, commonly referred to as a “Power Conditioner” or “Isolator Module”. Its primary function is to provide a safe, reliable, and conditioned DC power source for field devices in the DeltaV system, while providing electrical isolation to protect the system core from field disturbances and faults.

2. Key Functions

• Power Conversion & Conditioning: It converts and stabilizes the primary +24 VDC power from the DeltaV electronic marshalling cabinet backplane into an isolated, filtered +24 VDC power supply dedicated to powering field devices, such as:

  • 4-20 mA transmitters (pressure, temperature, flow, etc.)

  • Smart valve positioners

  • Solenoid valves for on/off valves

  • Other two-wire or three-wire field instruments.

• Electrical Isolation: This is its most critical function. It provides 1500 VAC current isolation between the system backplane (control system side) and the field wiring (hazardous area side). This prevents:

  • Measurement errors and signal noise caused by ground loops.

  • Voltage transients, surges, or faults on the field side from damaging expensive control system cards (e.g., I/O cards).

  • The propagation of faults between different parts of the system.

• Current Limiting & Protection: The module features built-in overcurrent protection, which limits the output current to prevent catastrophic failures due to field shorts and ensures a fault in one channel does not affect other channels on the same power module.

• Status Indication: The module is typically equipped with LED indicators to display power status and fault conditions, facilitating quick diagnostics.

3. Physical and Installation Characteristics

• Form Factor: It is a compact module designed to plug into a specific carrier or base unit within the DeltaV system.

• Mounting Location: It is installed on DIN rails inside a DeltaV electronic cabinet. A typical power conditioning carrier board can hold multiple DCDC modules.

• Connections: Power input is automatically obtained through the module’s connection to the backplane. The power output for field devices is connected via plug-in terminal blocks, simplifying wiring and maintenance.

4. Technical Specifications (Typical)

• Input Voltage: +24 VDC (from the DeltaV power system or backplane).

• Output Voltage: Isolated +24 VDC.

• Output Current: Each module typically provides up to 4 isolated output channels.

  • Max Output Current per Channel: Typically around 55 mA.

  • Total Max Output Current per Module: Typically around 220 mA (4 channels x 55 mA).

• Isolation Strength: 1500 VAC for 1 minute (between input, output, and channels).

• Operating Temperature: -40°C to +70°C (suitable for industrial environments).

• Certifications: Typically carries certifications like ATEX, IECEx for use in hazardous areas (depending on the specific model suffix).

5. Application and Importance in the DeltaV System

• Role: The 73-610-115 is a key component of the DeltaV S-series I/O system. It does not process the signal itself but provides power to field devices connected to AI (Analog Input), AO (Analog Output), and DI (Digital Input) cards.

• Typical Application Scenarios:

  1. Powering Two-Wire Transmitters: In a typical 4-20 mA analog input loop, the DCDC module provides the required loop power, while the AI card only measures the current signal.

  2. Powering Active Digital Devices: It powers digital input devices like proximity switches and solenoid valves that require an external power supply.

  3. Enabling Intrinsic Safety [ia/ib] Applications: When used with DeltaV intrinsic safety barriers, the DCDC module acts as an “associated apparatus,” providing power and isolation for the non-hazardous area control system side.
