ABB 216EA61B Analogue Input Unit for REG 216
ABB 216EA61B Analogue Input Unit for REG 216
The ABB 216EA61B Analogue Input Unit for REG 216 is a 24-channel A/D conversion module for the REG216 generator protection system. It receives stepped-down ±40 V signals from the 216GW61 input transformer, digitizes them with an on-board 80C186 processor, and transmits data over the B448C parallel bus. Powered by 24 V DC, it features 128 kB EPROM, 64 kB RAM, 8 kB EEPROM, built-in reference-voltage and self-test diagnostics. Manufactured in Sweden.
•Manager: Tiana Lai
•E-mail: ydf8801@163.com
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
ABB 216EA61B Analogue Input Unit for REG 216
The ABB 216EA61B Analogue Input Unit for REG 216 is a precision A/D conversion module built for the REG216 / REC216 digital generator protection system. It receives stepped-down current and voltage signals from the 216GW61 input transformer module, digitizes them on-board, and forwards the measured values to the processing unit over the B448C parallel bus.
Key Features
- 24 analog input channels, split across two D-sub connectors (a: CH01–CH12, b: CH13–CH24)
- Input range ±40 V, fed from the 216GW61 / 216GW62 input transformer
- On-board 80C186 processor for signal pre-processing
- Local memory: 128 kB EPROM (program), 64 kB RAM, 8 kB EEPROM (data)
- Up to two input transformer modules (216GW61) per 216EA61B
- Self-monitoring: reference voltage check, analog section supply watch, RAM/ROM test
- Plug-in module, 2 standard divisions (2T) wide, for 216MB66 equipment rack
Technical Specifications
| Item | Detail |
|---|---|
| Type Designation | 216EA61B |
| Order Code | HESG448230R1/G |
| Function | Analog input / A/D converter |
| Analog Inputs | 24 channels (CH01…CH24) |
| Input Signal Range | -40 V … +40 V (from 216GW61 transformer) |
| Connectors | “a” upper = CH01–CH12; “b” lower = CH13–CH24 |
| On-board Processor | 80C186 |
| Program Memory | 128 kB EPROM |
| Main Memory | 64 kB RAM |
| Data Memory | 8 kB EEPROM |
| Bus Interface | 64 kB DPM/RAM, B448C parallel bus |
| Auxiliary Supply | 24 V DC (from station battery via 216NG61/62/63) |
| Internal Voltage | 5 V DC (derived from 24 V) |
| Width | 2 T (standard divisions, plug-in) |
| Compatible Transformers | Up to 2× 216GW61 per unit |
| Origin | Sweden |
Installation Notes
- Insert the 216EA61B into rack divisions 8–9 or 10–11 on the 216MB66 rack; the B448C bus connector engages at the rear.
- Connect the analog signal cables from the 216GW61 input transformer module to connectors “a” and “b” — do not wire CT/PT secondary circuits directly to this unit.
- Verify the 24 V auxiliary supply LED is lit; internal 5 V generation is automatic.
- Channel assignment and scaling are configured via the portable HMI on the 216VC62a processor, not via on-board switches.
- On ALARM, check for VREF (reference voltage out of tolerance), ASE (analog section supply failure), or RAM/ROM error in the device status register.
Common Questions
How many analog signals can one 216EA61B measure? The unit has 24 A/D channels, but the usable measurement count depends on the number of 216GW61 input transformer modules connected: one transformer yields 12 signals, two yield 24.
Can I connect 4–20 mA field signals directly? No. This module sits behind the 216GW61 input transformer, which steps down primary CT/PT signals to ±40 V level. It is not a general-purpose 4–20 mA PLC analog input card.
What happens if the reference voltage drifts? The unit flags a VREF status bit (0400 Hex) and raises an ALARM; the protection system treats the affected analog channel as invalid until the fault is cleared.
